Capsule Protocol

The Capsule Protocol lets one person fund an agent’s LLM quota for a specific task without sharing provider credentials. A contract owner creates a ContractAction for an agent’s public key. A funder then attaches a finite CapsuleAction budget to that contract through any compatible funding client. These are distinct protocol roles, although the same person may perform both.

The protocol is application-agnostic. Any client can create or fund a contract, and any agent harness that can keep an ed25519 private key and make HTTP calls can redeem it. Pinard can create contracts as well as execute them; Pinard integration explains its pre-spawn gate, vendangeur runtime, reporting, and parking behavior.

Contract owner Funder Mnemosyne Pinard daemon Vendangeur LLM provider

1Owner → MnemosyneCreate a contract for the agent key and publish its contract ID.

2Funder → MnemosyneAttach a finite Capsule budget through a compatible funding client.

3Agent ↔ MnemosyneRead the contract first; when funded, discover the active Capsule.

4Agent ↔ Mnemosyne → providerSign redemption, obtain a short-lived token, and perform model work.

5Agent → MnemosyneReport cumulative usage periodically and post the final result.

6Pinard integrationGate before spawn; run in a vendangeur; park safely on exhaustion.

1. 1Create contract — any compatible client, including Pinard, can register the task and agent public key.
2. 2Fund contract — a funder uses a compatible client to create the live CapsuleAction budget.
3. 3Verify & discover — read the ContractAction, confirm the key and funding marker, then look up the Capsule.
4. 4Redeem & work — the agent signs with its private key and spends only the returned provider token.
5. 5Report & finish — usage and result content return to Mnemosyne without blocking the work loop.
6. 6Pinard-specific — the daemon gates spawning; the vendangeur redeems; exhausted work is parked without fallback credentials.

1. Roles and data model

The ContractAction and CapsuleAction deliberately have different lifetimes. Read the stable contract first to verify the task and agent key; only after it reports funding should the agent discover the current live Capsule.

2. Create, fund, verify, and discover

2a. Create the contract

The contract owner creates a ContractAction containing the work description and the agent’s public key. The returned Mnemosyne action ID is the contract_id published with the task. Contract creation is client-independent; Pinard’s creation path is documented under Pinard integration.

2b. Fund the contract

The funder supplies that contract_id to any compatible funding client, which creates a CapsuleAction with a finite call budget. Funding does not transfer provider credentials to the contract owner or agent.

2c. Read and verify the contract

Before capsule lookup, the agent reads:

GET {MNEM}/actions/<contract_id>/do

No authentication is required. The response includes description, public_key, result_url, and patch_url_encrypted.

• patch_url_encrypted: null means the contract is not funded yet.
• A base64 string means funding exists and the agent may continue to lookup.
• public_key MUST match the agent’s own key; a mismatch is a permanent failure.
• Network and 5xx errors are transient and should be retried.

2d. Discover the live Capsule

GET {MNEM}/capsules/lookup?contract_id=<id>

No authentication required. Response (200 OK):

{
  "do_url":             "<url to the capsule's signed /do endpoint>",
  "calls_allowed":      10,
  "calls_succeeded":    3,
  "claimed":            true,
  "result_url":         "<funder-visible result page URL>",
  "patch_url_encrypted": "<base64 AES-GCM ciphertext of result_patch_url>",
  "contract_stats_url": "<URL for usage reporting>"
}

Status codes:

The do_url belongs to the CapsuleAction, not the ContractAction. result_url is public; patch_url_encrypted protects the write URL; and contract_stats_url receives usage.

3. Agent-side signed redemption

Once the agent has verified the contract (§2c) and discovered the Capsule (§2d), it redeems the capsule by performing a signed GET to the capsule’s do_url (obtained from the lookup response).

Signing

Construct the message to sign (newline-separated, no trailing newline):

GET\n<path>\n<ISO-8601 timestamp>\n<nonce>

Where:

• <path> is the URL path component of do_url (e.g. /actions/<id>/do) — not the full URL with query string.
• <ISO-8601 timestamp> is the current UTC time in 2006-01-02T15:04:05Z format.
• <nonce> is any unique string for this request; UUID v4 is recommended. Mnemosyne rejects duplicates seen within 120 seconds.

Sign the UTF-8 encoding of this message with the agent’s ed25519 private key. Encode the signature as standard base64.

Request

GET <do_url>
Authorization: Signature key=<pubkeyB64>,timestamp=<ts>,nonce=<nonce>,sig=<sigB64>

• <pubkeyB64> — base64-encoded raw 32-byte ed25519 public key (matching the contract).
• <ts> — the same ISO-8601 timestamp used in the signed message.
• <nonce> — the same nonce used in the signed message.
• <sigB64> — base64-encoded ed25519 signature.

Atomic first claim

On the first successful redemption, Mnemosyne atomically records the presented public key as the Capsule’s claiming_key. If two agents race, exactly one succeeds. Later redemptions must be signed by the same key.

Portable response

The portable protocol guarantees a successful response containing the short-lived provider token. The current Pinard/Mnemosyne integration also accepts a JSON envelope on first claim:

{
  "token":      "<short-lived JWT for the LLM provider>",
  "result_key": "<base64 AES-256 key>",
  "owner":      "<funder username>"
}

• token — the LLM token to use for this session. It is short-lived; the agent MUST re-redeem (§3) on token expiry to obtain a fresh one.
• result_key — present only on first claim. Used to decrypt patch_url_encrypted (§4). On refresh responses this field is absent.
• owner — the funder’s identity (Mnemosyne v0.21.0+); may be absent.

Response (refresh)

On token refresh, the current integration may return a bare JWT string instead of the JSON envelope:

eyJhbGciOiJSUzI1NiJ9.eyJzdWIiOiJ1c2VyIn0.c2lnbmF0dXJl

Pinard accepts both forms:

1. Try JSON parse first; if token is non-empty, use it.
2. Otherwise, if the response starts with eyJ and contains exactly two . separators, treat the whole body as a bare JWT.

On refresh, result_key is absent. The client MUST reuse the result_patch_url cached from the first-claim response (§4).

Redemption status codes

The timestamp may differ from server time by at most 60 seconds. The nonce deduplication window is 120 seconds.

4. Result key and result posting

patch_url_encrypted (from the lookup response, §2d) is an AES-GCM ciphertext of the URL to which the agent should post its result. The nonce is prepended to the ciphertext (standard nonce-prepend convention).

Decrypt on first claim:

1. Base64-decode patch_url_encrypted → raw ciphertext bytes.
2. Base64-decode result_key → 32-byte AES-256 key.
3. AES-GCM decrypt: split the first NonceSize() (12) bytes as the nonce; decrypt the remainder with no additional data.
4. The plaintext is the result_patch_url (a URL string; trim whitespace).

Cache result_patch_url locally (e.g. in a run-state file). On refresh, result_key is absent — the cached URL is reused.

Posting the result

When the task is complete, PATCH its result to result_patch_url:

PATCH <result_patch_url>
Content-Type: application/json

[
  {"op": "replace", "path": "/content_type", "value": "text/markdown"},
  {"op": "replace", "path": "/data",         "value": "<result content>"}
]

No authentication is required for this PATCH because the unguessable URL is itself the credential. The result may be Markdown, HTML, JSON, or another agreed MIME type.

5. Usage reporting

While work is in progress, the agent SHOULD periodically report token usage to allow the funder to monitor consumption. This is authless:

PATCH <contract_stats_url>
Content-Type: application/json

{
  "model":             "claude-sonnet-4-5",
  "input_tokens":      12345,
  "output_tokens":     6789,
  "cache_read_tokens": 1000,
  "tool_calls":        42,
  "compactions":       1
}

Reporting is advisory. PATCH failures MUST be logged but MUST NOT crash or stop the agent. A final flush SHOULD be sent when the agent session ends.

6. Lifecycle and failure semantics

contract created → unfunded → funded → active → completed
                                               ↘ exhausted → [refunded?] → active
                    ↘ mismatch/error → failed (permanent)

The following are protocol requirements (MUST / MUST NOT):

Fail-closed invariant: when an agent is capsule-gated (a contract is associated with the work item), it MUST NEVER acquire a token from any other source. The funder’s quota is the only permitted source. An operator token, a default API key, or any other fallback MUST NOT be used, regardless of capsule state.

Parking vs. failure: a temporarily exhausted capsule MAY be refilled by the funder. An implementation SHOULD “park” the run (persist state so it can be resumed) rather than closing it permanently. A pubkey mismatch or permanent authorization error, however, is a permanent failure.

Pinard integration

Pinard can create the ContractAction and can run the agent that redeems the resulting Capsule. The mechanics below are Pinard-specific and are not portable protocol requirements.

Where Pinard participates

1. The régisseur or aoc capsule-contract creates a ContractAction and publishes its ID on the GitLab issue.
2. An external, compatible funding client creates the CapsuleAction for that ID.
3. The daemon waits for a funded, matching contract before it spawns a vendangeur.
4. The vendangeur calls aoc capsule-redeem, reports usage, and posts the result.
5. Pinard parks exhausted work and never substitutes an operator token.

Compatibility note: the current daemon checks Capsule lookup before it probes the ContractAction, while the portable protocol specifies contract-first ordering. Both checks must succeed before Pinard spawns work. Current Pinard also accepts the deployed Mnemosyne compatibility responses 401, signed-/do 404, and 410; these should not be treated as portable status-code definitions.

Build tag requirement

The capsule commands (aoc capsule-keygen, aoc capsule-pubkey, aoc capsule-contract, aoc capsule-redeem) and the capsule-aware daemon logic are compiled only when aoc is built with -tags capsule. The release bundle handles this automatically. When building from source, ./install detects the capsule source files and adds the tag automatically.

Identity keypair

aoc capsule-keygen          # generates ~/.config/pinard/capsule_key.pem (mode 0600)
aoc capsule-pubkey          # prints the base64 public key to share with funders
aoc capsule-keygen --force  # rotate (existing contracts tied to old key will be declined)

Creating a contract with Pinard

The régisseur’s create_contract tool authenticates to Mnemosyne via device-auth flow (tokens cached at ~/.config/pinard/mnemosyne-tokens.json), creates the ContractAction with the host’s pubkey, and posts a structured comment on the GitLab issue containing the contract_id: line that the daemon detects automatically.

From the CLI:

aoc capsule-contract \
  --title "Add GWAS pipeline stage" \
  --description "Implement imputation for issue #42" \
  --repo mygroup/myproject \
  --issue 42

Lifecycle labels (durable poll state)

The daemon rebuilds its poll set from GitLab labels on restart — labels are the durable state, not in-memory structures.

Run state file

aoc capsule-redeem <contract_id> (called by the vendangeur at token-refresh time) writes <rundir>/capsule.json:

{
  "contract_id":       "<id>",
  "do_url":            "<cached do_url for refresh>",
  "result_patch_url":  "<decrypted result posting URL>",
  "contract_stats_url":"<URL for usage PATCH>",
  "result_url":        "<funder-visible result page>"
}

On token refresh the daemon skips the lookup round-trip and re-signs do_url directly.

Environment variables

Capsule-aware orphan recovery

When the daemon’s orphan recovery restarts a dead capsule run, it probes /capsules/lookup first. If the capsule is exhausted (404/410), it parks the run and relabels the issue capsule:awaiting-funding instead of respawning. It will never restart a capsule run on the operator token.
